Lincoln MKX I facelift (2010-2015) (body main wiring harness in breakout Wiring diagram
This page shows the only wiring diagram for the component.(body main wiring harness in breakout, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (body main wiring harness in breakout (1 of 1)
1 2 3 4 5 6 7 8 VBATT HS CAN+ HS CAN-
BACKLIGHTING LED (FET)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DRIVER SIDE DOOR LOCK SWITCH
FLOOR SHIFTER ILLUMINATION
FRONT LIGHTING CONTROL MODULE (LEFT SIDE OF DASH)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HS CAN + HS CAN -
HS HS CAN+ CAN-
LEFT REAR SEAT HEATER SWITCH
MEDIA HUB ILLUMINATION
MEMORY SET SWITCH
MICRO -
MULTI- FUNCTION SWITCH
NCA WIRE
PASSENGER SIDE DOOR LOCK SWITCH
PASSENGER SIDE WINDOW ADJUST SWITCH
POWER LIFTGATE RELEASE SWITCH
RIGHT REAR SEAT HEATER SWITCH
START/STOP SWITCH (W/ INTELLIGENT ACCESS) (CENTER OF DASH)
STEERING COLUMN CONTROL MODULE (SCCM) (STEERING COLUMN)
VIO WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> (BODY MAIN WIRING HARNESS IN BREAKOUT
