Lincoln MKX I facelift (2010-2015) 31 52 56 34 34 51 31 21 8 acpt vref sigrtn fcv fcv Wiring diagram
This page shows the only wiring diagram for the component.31 52 56 34 34 51 31 21 8 acpt vref sigrtn fcv fcv, which is found in the car Lincoln MKX I facelift (2010-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 31 52 56 34 34 51 31 21 8 acpt vref sigrtn fcv fcv (1 of 1)
12 58 59 10 41 54 ACCR HS CAN - HS CAN +
3.5L/3.7L
31 52 56 34 34 51 31 21 8 ACPT VREF SIGRTN FCV FCV
4 3 2 1 FAN CNTRL
66 12 56 34 EVDC ECT CHT SIGRTN
A/C CLUTCH RELAY
A/C COMPRESSOR CLUTCH FIELD COIL (A/C COMPRESSOR)
A/C PRESSURE TRANSDUCER SENSOR (RIGHT FRONT OF ENGINE COMPT)
AAT
AMBIENT AIR TEMPERATURE (AAT) SENSOR (RIGHT FRONT OF ENGINE COMPT)
AUTO LAMP SENS IN CAN+
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN MOTORS
CYLINDER HEAD TEMPERATURE SENSOR (FRONT OF RIGHT CYLINDER BANK)
ELECTRONICS COOLING FAN MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR (2.0L)
EXTERNALLY CONTROLLED VARIABLE DISPLACEMENT COMPRESSOSR (EVDC) (2.0L)
FUSE 39
FUSE 40
FUSE 62
FUSE 70
GND PWR
GRN WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
MICRO -
MS CAN +
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT)
RED WIRE
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
W/O TRAILER TOW W/ TRAILER TOW 2.0L 3.5L/3.7L
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> 31 52 56 34 34 51 31 21 8 ACPT VREF SIGRTN FCV FCV
