Lincoln MKX I facelift (2010-2015) 21 22 23 24 lr spkr + lf spkr + rf spkr + rr spkr + Wiring diagrams
This page contains all the electrical diagrams for the component. 21 22 23 24 lr spkr + lf spkr + rf spkr + rr spkr +, in which he is found in the car Lincoln MKX I facelift (2010-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 21 22 23 24 lr spkr + lf spkr + rf spkr + rr spkr + (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VBATT ANTENNA PWR
1 2 3 4 5 6 7 8 9 10 11 12 VBATT
21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
AUDIO CONTROL MODULE (ACM) (CENTER OF DASH)
AUDIO INPUT JACK
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
CLOCKSPRING (STEERING COLUMN)
CLUSTER SYSTEM
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM NAVIGATION SYSTEM
CRUISE CONTROL SYSTEM
DOWN
FRONT CONTROL/ DISPLAY INTERFACE
FUSE 29 FUSE 23
FUSE 5
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BODY CONTROL MODULE FUSE 19 (BCM) (LEFT KICK PANEL)
I CAN+ I CAN- VIDEO+
LEFT MEDIA
MODULE (FCDIM) (CENTER OF DASH)
MUTE
NAVIGATION SYSTEM
NCA WIRE
PWR
RIGHT
RIGHT STEERING WHEEL SWITCH
SEEK
SHIELD CNTR SPKR -
STARTING/ CHARGING SYSTEM
STATE SOLID
SUB +
SUB ENABLE
SUB SHIELD SUB- SUB ENABLE
SUBWOOFER
VIDEO+
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VOL (-)
W/ SATELLITE RADIO
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, with premium (1 of 2) -> 21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
Wiring diagram 21 22 23 24 lr spkr + lf spkr + rf spkr + rr spkr + (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VBATT ANTENNA PWR
1 2 3 4 5 6 7 8 9 10 11 12 VBATT
21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
AUDIO CONTROL MODULE (ACM) (CENTER OF DASH)
AUDIO INPUT JACK
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
CLOCKSPRING (STEERING COLUMN)
CLUSTER SYSTEM
COAXIAL CABLE COAXIAL CABLE
COAXIAL CABLE COAXIAL CABLE SDARS AM/FM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM NAVIGATION SYSTEM
CRUISE CONTROL SYSTEM
DOWN
FRONT CONTROL/ DISPLAY INTERFACE
FUSE 29 FUSE 23
FUSE 5
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BODY CONTROL MODULE FUSE 19 (BCM) (LEFT KICK PANEL)
I CAN+ I CAN- VIDEO+
LEFT MEDIA
MODULE (FCDIM) (CENTER OF DASH)
MUTE
NAVIGATION SYSTEM
NCA WIRE
PWR
RIGHT
RIGHT STEERING WHEEL SWITCH
SEEK
SHIELD CNTR SPKR -
STARTING/ CHARGING SYSTEM
STATE SOLID
SUB +
SUB ENABLE
SUB SHIELD SUB- SUB ENABLE
SUBWOOFER
VIDEO+
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VOL (-)
W/ SATELLITE RADIO
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Premium radio circuit (1 of 2) -> 21 22 23 24 LR SPKR + LF SPKR + RF SPKR + RR SPKR +
