Heated seats circuit, rear seats for Lincoln MKX I (2006-2010)

BACK BACKLIGHTING BATT-DR BATT-PASS BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BLU/WHT WIRE CUSHION) FUSE 35 FUSE 7 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRY/BLU WIRE GRY/BRN WIRE HOT AT ALL TIMES LEFT REAR HEATED SEAT MODULE (UNDER LEFT REAR SEAT) LEFT REAR SEAT HEATER ELEMENT (UNDER LEFT REAR SEAT) LEFT REAR SEAT HEATER SWITCH LR HEATER LR HI LED LR HI/OFF LR LO LED LR LO/OFF LR TEMP SENS OFF/HI OFF/LO RIGHT REAR SEAT HEATER ELEMENT RIGHT REAR SEAT HEATER SWITCH RR HEATER RR HI LED RR HI/OFF RR LO LED RR LO/OFF RR TEMP SENS RUN/START SENS RTN SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO WIRE VIO/GRN WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE
