Lincoln MKX I (2006-2010) sens gnd Wiring diagram
This page shows the only wiring diagram for the component.sens gnd, which is found in the car Lincoln MKX I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens gnd (1 of 1)
BATTERY JUNCTION
BLK/GRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 51 BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
GND SENS GND
GRN/BRN WIRE
GRN/VIO WIRE
GRY/VIO WIRE
HEADLAMP CONTROL MODULE (HCM) LEFT HEADLAMP
HOT AT ALL TIMES
HS CAN+
RIGHT HEADLAMP
SENS GND
SENS SIG VCC
STEERING ANGLE SENSOR MODULE (SASM) (ON STEERING COLUMN)
VIO/GRY WIRE
VPWR SENS SIG VCC HS CAN +
WHT WIRE
WHT/BLU WIRE
YEL/GRY WIRE
Go to component -> Adaptive front lighting circuit -> SENS GND
