Lincoln MKX I (2006-2010) right side exterior rear view mirror Wiring diagrams
This page contains all the electrical diagrams for the component. right side exterior rear view mirror, in which he is found in the car Lincoln MKX I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right side exterior rear view mirror (1 of 2)
BATTERY SAVER RELAY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU/WHT WIRE
CARGO LAMP
CENTER INTERIOR LAMPS
DIM DOME SW DIMMER LF DOOR RF DOOR LP GND SW AJAR AJAR
FUSE
FUSE OFF
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY/VIO WIRE
HOMELINK MODULE
HOT AT ALL TIMES
ILLUMINATION DIMMER
INTERIOR LIGHTING (FET)
LEFT FRONT DOOR LOCK ACTUATOR (REAR OF DRIVER'S DOOR)
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LEFT VANITY MIRROR LAMP
LR DOOR AJAR
MICRO -
OFF
OVERHEAD CONSOLE
PUDDLE LAMP
PUDDLE LAMP (FET)
RED WIRE
RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF FRONT PASSENGER'S DOOR)
RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR)
RIGHT SIDE EXTERIOR REAR VIEW MIRROR
RIGHT VANITY MIRROR LAMP
RR DOOR AJAR
SMART JUNCTION BOX (SJB)
VIO WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit -> RIGHT SIDE EXTERIOR REAR VIEW MIRROR
Wiring diagram right side exterior rear view mirror (2 of 2)
BLK WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
DOWN UP
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 12
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT RIGHT
LEFT SIDE EXTERIOR REAR VIEW MIRROR
LEFT/ RIGHT UP/ DOWN
MIRROR SELECT
RIGHT DOWN LEFT
RIGHT LEFT
RIGHT SIDE EXTERIOR REAR VIEW MIRROR
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
YEL/VIO WIRE
Go to component -> Power mirrors circuit -> RIGHT SIDE EXTERIOR REAR VIEW MIRROR
