Lincoln MKX I (2006-2010) rev lmp ctl 17 18 19 32 Wiring diagram
This page shows the only wiring diagram for the component.rev lmp ctl 17 18 19 32, which is found in the car Lincoln MKX I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rev lmp ctl 17 18 19 32 (1 of 1)
AUTO DIMMING INTERIOR MIRROR
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN WIRE
EDGE MKX
FUSE 44
GRN WIRE
GRN/BRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT REVERSING LAMP
POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE)
REV LMP CTL 17 18 19 32
REVERSING LAMPS RELAY
RIGHT REVERSING LAMP
VIO WIRE
VIO/WHT WIRE
W/ MICROPHONE
W/O MICROPHONE, W/ ILLUM VISOR W/O MICROPHONE, ILLUM VISOR
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> REV LMP CTL 17 18 19 32
