Lincoln MKX I (2006-2010) rear seat release relay Wiring diagrams
This page contains all the electrical diagrams for the component. rear seat release relay, in which he is found in the car Lincoln MKX I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear seat release relay (1 of 2)
A/C CLUTCH RELAY
ACCESSORY PROTOCOL INTERFACE MODULE (APIM)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/VIO WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRAKE PEDAL POSITION (BPP) SWITCH
CARGO AREA)
CONSOLE 1 POWER POINT
CONSOLE 2 POWER POINT
CONSOLE REAR
DRIVER SEAT LEFT MODULE POWER (DSM) SEAT SWITCH
FLOOR LIGHTING LOW BEAM
FROM FUSE 63 IN BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 5)
FROM MEGA FUSE IN BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 5)
FROM RUN/ START RELAY IN BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 5)
FUEL PUMP RELAY
FUSE
FUSE 1 FUSE 4 FUSE 2
FUSE 10
FUSE 17
FUSE 3
FUSE 5
FUSE 6
FUSE 60
FUSE 61
FUSE 63
FUSE 64
FUSE 65
FUSE 66
FUSE 7 FUSE 8
FUSE 71
FUSE 9
GRN WIRE
GRY WIRE
HEATED MIRROR RELAY
INSTRUMENT PANEL POWER POINT
KEYPAD BSI ILLUM (FET) (FET)
LEFT INTERIOR RIGHT LOW
LEFT REAR SEAT ENABLE TURN LAMP (FET) (FET)
LEFT REAR STOP/ TURN LAMP (FET)
MANUAL A/C
PCM POWER RELAY
POWER POINT
REAR ENTERTAINMENT MODULE (RETM)
REAR SEAT RELEASE RELAY
RED WIRE
REVERSING LAMPS RELAY
RIGHT FRONT LEFT FRONT TURN LAMP TURN LAMP (FET) (FET)
RIGHT REAR RIGHT REAR TURN LAMP STOP/TURN (FET) LAMP (FET)
RIGHT RIGHT POWER POWER SEAT SWITCH SEAT SWITCH
STARTER RELAY
TO FUSE 11 IN SMART JUNCTION BOX (SJB) (DIAGRAM 3 OF 5)
TO FUSE 60 IN BATTERY JUNCTION BOX (BJB)
TPMS 1 TPMS 2 TPMS 3 (FET) (FET) (FET)
TRAILER TOW LEFT STOP/TURN LAMP RELAY
TRAILER TOW RIGHT STOP/TURN LAMP RELAY
VIO WIRE
W/ 6-WAY W/ 10-WAY POWER POWER PASSENGER PASSENGER SEAT SEAT
W/ EDGE
W/ MKX
W/ W/O MEMORY MEMORY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> REAR SEAT RELEASE RELAY
Wiring diagram rear seat release relay (2 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
FUSE
FUSE 27
GRN/BRN WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT)
LEFT
LEFT REAR SEAT RELEASE ACTUATOR (UNDER LEFT REAR SEAT)
MICRO -
REAR POWER SEAT RELEASE SWITCH
REAR SEAT RELEASE RELAY
RIGHT
RIGHT REAR SEAT RELEASE ACTUATOR (UNDER RIGHT REAR SEAT)
SEAT ENABLE (FET)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
WHT/BRN WIRE
Go to component -> Second row seat release circuit -> REAR SEAT RELEASE RELAY
