Lincoln MKX I (2006-2010) internal tpms antenna Wiring diagram
This page shows the only wiring diagram for the component.internal tpms antenna, which is found in the car Lincoln MKX I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram internal tpms antenna (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
FUSE
HOT AT ALL TIMES
INTERNAL TPMS ANTENNA
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
LOGIC PWR GND GND
MEGA
MICRO -
RED WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SPARE TIRE PRESSURE SENSOR
TPMS RECEIVER
VBATT
Go to component -> Tire pressure monitoring circuit -> INTERNAL TPMS ANTENNA
