Lincoln MKX I (2006-2010) (in power seats wiring harness, near breakout to Wiring diagram
This page shows the only wiring diagram for the component.(in power seats wiring harness, near breakout to, which is found in the car Lincoln MKX I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in power seats wiring harness, near breakout to (1 of 1)
BACK
BATT-DRV
BATT-PASS
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/BLU WIRE
CUSHION)
DATC HVAC MODULE
DRV HI LED
DRV HI/LO/OFF
DRV LO LED
FRONT PASSENGER SIDE HEATED SEAT MODULE (UNDER FRONT PASSENGER'S SEAT)
FUSE 16
FUSE 35
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT HEATER ELEMENT (IN DRIVER'S SEAT CUSHION) CUSHION
LF HEATER
LF TEMP SENS
PASS HI LED
PASS HI/LO/OFF
PASS LO LED
RF HEATER
RF TEMP SENS
RIGHT FRONT SEAT HEATER ELEMENT (IN FRONT PASSENGER'S SEAT CUSHION)
RUN/START
SENS RTN
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO WIRE
VIO/BRN WIRE
VIO/RED WIRE
WHT/BLU WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Heated seats circuit, front seats -> (IN POWER SEATS WIRING HARNESS, NEAR BREAKOUT TO
