Computer data lines circuit for Lincoln MKT I (2009-2012)

1 2 HS CAN + HS CAN - 17 18 MS CAN+ MS CAN- 3.5L 3.7L BLK/BLU WIRE BRN WIRE DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) FEPS FUSE 20 GRN/RED WIRE GRY/ORG WIRE HEAD UP DISPLAY (HUD) MODULE (LEFT SIDE OF DASH) HEATED/COOLED SEAT) PASSENGER CLIMATE CONTROLLED SEAT MODULE 2 (PCSM-2) HOT AT ALL TIMES HS CAN+ INSTRUMENT PANEL CLUSTER (IPC) INTERIOR LIGHTING CONTROL MODULE (ILCM) (UNDER CENTER CONSOLE) J/C 2 (RIGHT SIDE OF DASH) J/C 4 (LOWER LEFT SIDE OF DASH) J/C 7 (BEHIND RIGHT KICK PANEL) J/C 9 (3.5L) (LEFT SIDE OF ENGINE COMPT) MS CAN + NEAR BREAKOUT TO POWER DISTRIBUTION SYSTEM POWER STEERING CONTROL MODULE (PSCM) (3.5L: RIGHT REAR OF ENGINE) POWERTRAIN CONTROL MODULE (PCM) (REAR OF ENGINE COMPT) REMOTE FUNCTION ACTUATOR (RFA) (RIGHT SIDE OF DASH) RHVAC MODULE (UNDER CENTER CONSOLE) SMART JUNCTION BOX (SJB) (LOWER LEFT SIDE OF DASH) STEERING ANGLE SENSOR MODULE (SASM) (W/ AUTO PARK) (TOP OF STEERING COLUMN) VIO/ORG WIRE WHT WIRE WHT/BLU WIRE

3.5L 3.7L 6 5 MS CAN - MS CAN + 9 10 MS CAN- MS CAN+ ANTI-LOCK BRAKE SYSTEM (ABS) MODULE (LEFT REAR OF ENGINE COMPT) AUDIO CONTROL MODULE (ACM) (CENTER OF DASH) DRIVER SEAT MODULE (DSM) (UNDER DRIVER'S SEAT) DUAL CLIMATE CONTROLLED SEAT MODULE (DCSM) FRONT CONTROL INTERFACE MODULE (FCIM) (LOWER CENTER OF DASH) GRY/ORG WIRE HEADLAMP CONTROL MODULE (HCM) (BEHIND LEFT HEADLIGHT ASSEMBLY) HIGH BEAM CONTROL MODULE 2 (HCM-2) HS CAN+ J/C 1 (LOWER LEFT END OF DASH) J/C 10 (RIGHT QUARTERPANEL) J/C 8 (NEAR LEFT "B" PILLAR) MIRROR LIGHT MS CAN + RIGHT REAR SIDE OBSTACLE DETECTION (SOD) SENSOR (RIGHT SIDE OF REAR BUMPER) VIO/ORG WIRE WHT WIRE WHT/BLU WIRE
