Auxiliary blower circuit for Lincoln MKT I (2009-2012)

12 13 AUX BLW RLY REQUEST AUX BLW POWER 15 14 17 MS CAN+ MS CAN- GND 4 3 RETURN VREF 6 5 4 3 2 1 GROUND PWM AUTOMATIC A/C CIRCUIT AUXILIARY BLOWER CONTROL MODULE (LEFT REAR QUARTERPANEL) AUXILIARY BLOWER MOTOR (LEFT REAR QUARTERPANEL) AUXILIARY BLOWER MOTOR RELAY AUXILIARY IN-VEHICLE TEMPERATURE SENSOR (BEHIND LEFT QUARTERPANEL) AUXILIARY MODE DOOR ACTUATOR (LEFT REAR QUARTERPANEL) AUXILIARY TEMPERATURE BLEND DOOR ACTUATOR (LEFT REAR QUARTERPANEL) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF OF ENGINE COMPT) BLK/BLU WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 31 FUSE 43 GRN WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HVAC-DATC MODULE (RIGHT SIDE OF DASH) POWER DISTRIBUTION SYSTEM RED WIRE RHVAC MODULE (UNDER CENTER CONSOLE) SMART JUNCTION BOX (SJB) (LOWER LEFT SIDE OF DASH) VBATT VIO WIRE VIO/BRN WIRE VIO/ORG WIRE VIO/WHT WIRE VPWR MOT - WHT WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
