Lincoln MKS I facelift (2012-2016) Cooling fan circuit

3.5L 3.7L ACTIVE GRILLE SHUTTER (AGS) BATTERY JUNCTION BOX (BJB) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/YEL WIRE BLU/GRY WIRE BRN WIRE BRN/RED WIRE CHT COMPUTER DATA LINES SYSTEM FUSE FUSE 29 FUSE 30 FUSE 69 FUSE 70 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HFC HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED HS CAN+ LFC LIN POWERTRAIN CONTROL MODULE (PCM) POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPT) PWR PWR GND RED WIRE SIG RTN VIO WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE

3.7L BATTERY JUNCTION BOX (BJB) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BLU/ORG WIRE BRN WIRE BRN/RED WIRE CYLINDER HEAD TEMPERATURE (CHT) SENSOR CYLINDER HEAD TEMPERATURE (CHT) SENSOR (3.5L: MIDDLE OF RIGHT CYLINDER HEAD) ENGINE CONTROLS SYSTEM ENGINE COOLING FAN MOTOR 1 ENGINE COOLING FAN MOTOR 1 (BEHIND LEFT SIDE OF RADIATOR) ENGINE COOLING FAN MOTOR 2 ENGINE COOLING FAN MOTOR 2 (BEHIND RIGHT SIDE OF RADIATOR) FAN CONTROL (FC) RELAY FUSE FUSE 31 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/RED WIRE HIGH FAN CONTROL (HFC) HIGH FAN CONTROL (HFC) RELAY JUNCTION WIRING HARNESS, NEAR BREAKOUT TO BATTERY JUNCTION BOX) LOW FAN CONTROL (LFC) RELAY ORG/ WIRE RED WIRE RELAY VIO WIRE WHT WIRE WHT/VIO WIRE
