Instrument illumination circuit for Lincoln MKS I (2008-2012)

ACTIVE PARK ASSIST SWITCH AMBIENT LIGHTING SWITCH AUTO BLK/BLU WIRE BLK/VIO WIRE BLU/WHT WIRE BRN WIRE CLOCKSPRING (STEERING COLUMN) FLOOR SHIFTER FUSE GRN WIRE GRY WIRE GRY/YEL WIRE HEAD- PARK HEAD- HEADLAMP SWITCH HOT AT ALL TIMES INSTRUMENT PANEL DIMMER SWITCH LEFT STEERING WHEEL SWITCH LOGIC DIM AUTO SW LAMP LAMPS LAMP LAMP GND OFF ON ON ON LUGGAGE COMPARTMENT LID RELEASE SWITCH (LUGGAGE COMPARTMENT LID) PARK OFF REAR SUNSHADE SWITCH RED WIRE REMOTE FUNCTION ACTUATOR(RFA) (RIGHT SIDE OF DASH) RIGHT STEERING WHEEL SWITCH S/S GND 2 SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) STEERING WHEEL) SWITCH (W/ IA) VIO/GRN WIRE WHITE LED (FET) WHT/ORG WIRE WHT/VIO WIRE
