Lincoln MKS I (2008-2012) multi-function headlamp switch switch wiring diagram
This page shows the only wiring diagram for the component.multi-function headlamp switch switch, which is found in the car Lincoln MKS I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
multi-function headlamp switch switch wiring diagram (1 of 1)
3.5L
3.7L
67 67 66 50 68 68 69 69 70 70 3.7L 3.5L
A/C COMPRESSOR CLUTCH FIELD COIL
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
AUTO HIGH BEAM RELAY
BATTERY
BLK WIRE
BLOWER MOTOR SPEED CONTROL
BRAKE FLUID LEVEL SWITCH
CLOCKSPRING (STEERING COLUMN)
CRUISE CONTROL MODULE
DATA LINK CONNECTOR (DLC)
ENGINE COOLING FAN MOTOR
FOG LAMP DEACTIVATION RELAY
FRONT CONSOLE POWER POINT
FUEL PUMP DIODE
GLOVE BOX LAMP)
GRN WIRE
GRY WIRE
HOOD SWITCH
HORN
HORN SWITCH
LEFT FRONT FOG LAMP
LEFT FRONT PARK/ TURN LAMP
LEFT HEADLAMP
LEFT HIGH REAR WINDOW REAR MOUNTED DEFROST LAMP STOPLAMP GRID ASSEMBLY
LEFT RIGHT FRONT FRONT FOOTWELL FOOTWELL LAMP LAMP
LEFT STEERING WHEEL SWITCH
MASS AIR FLOW/ INTAKE AIR TEMPERATURE (MAF/IAT) SENSOR
MULTI-FUNCTION HEADLAMP SWITCH SWITCH
POWER STEERING CONTROL MODULE (PSCM)
POWERTRAIN CONTROL MODULE (PCM)
REAR CONSOLE POWER POINT
REAR OF ENGINE COMPT)
RED WIRE
RELAY
REMOTE FRONT FUNCTION CIGAR ACTUATOR (RFA) LIGHTER
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT HEADLAMP
RIGHT STEERING WHEEL SWITCH
RUN/
STEERING LUGGAGE COLUMN COMPARTMENT POSITION LID RELEASE SWITCH SWITCH
STEERING WHEEL)
VIO WIRE
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMP MOTOR
WINDSHIELD WIPER MOTOR
WIPER RUN/ PARK RELAY
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> MULTI-FUNCTION HEADLAMP SWITCH SWITCH
