Lincoln MKC I facelift (2018-2019) w/ rain sensing wipers Wiring diagram
This page shows the only wiring diagram for the component.w/ rain sensing wipers, which is found in the car Lincoln MKC I facelift (2018-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rain sensing wipers (1 of 1)
AUDIO CONTROL MODULE (ACM)
AUTO DIMMING INTERIOR MIRROR
CRUISE CONTROL MODULE (CCM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/ORG WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
ORG/ WIRE
RESTRAINTS CONTROL MODULE (RCM)
STEERING COLUMN CONTROL MODULE (SCCM)
VEHICLE DYNAMICS MODULE (VDM)
VIO/ORG WIRE
W/ RAIN SENSING WIPERS
W/ START/STOP
W/ THX
W/O THX
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
Go to component -> Computer data lines circuit (2 of 4) -> W/ RAIN SENSING WIPERS
