Lincoln MKC I facelift (2018-2019) park lps on wiring diagram
This page shows the only wiring diagram for the component.park lps on, which is found in the car Lincoln MKC I facelift (2018-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
park lps on wiring diagram (1 of 1)
AUTOLAMP
AUTOLAMP ON
B+ SW
BALLAST B+
BALLAST GND
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIM +
DRL
FRONT FOG
FRONT FOG LAMP SWITCH
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
H/L ON
HEAD/PARK
HEADLAMP LEVELING
HEADLAMP SWITCH
HI BEAM
HILL OUT
ILLM GND
ILLUM
LAMP GND
LO BEAM REQ
LOW BEAM
LPS OFF
MICRO -
MULTI- FUNCTION SWITCH
OFF
PARK
PARK LPS ON
RIGHT HEADLAMP ASSEMBLY
STEERING COLUMN CONTROL MODULE (SCCM)
TURN
TURN GND
USED)
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Headlights circuit (3 of 3) -> PARK LPS ON
