Lincoln MKC I facelift (2018-2019) ecu mode Wiring diagrams
This page contains all the electrical diagrams for the component. ecu mode, in which he is found in the car Lincoln MKC I facelift (2018-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
ecu mode wiring diagram (1 of 4)
ACTIVE GRILLE SHUTTER
AIR CONDITIONING (A/C) PRESSURE TRANSDUCER
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BRN WIRE
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
ECU MODE
FUSE 18
FUSE 34
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
ORG/ WIRE
RED WIRE
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/o trailer tow (4 of 5) -> ECU MODE
ecu mode wiring diagram (2 of 4)
2.3L TURBO 2.0L TURBO
AAT
ACCRC
ACPT
ACTIVE GRILLE SHUTTER
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECT
ECU MODE
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE (ECT) SENSOR
ENGINE COOLING FAN RESISTOR 1
FUSE 16
FUSE 17
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HFC
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LFC
MFC
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM)
PWM
RED WIRE
SIGRTN
SSC CTRL
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
VREF
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ trailer tow (5 of 5) -> ECU MODE
ecu mode wiring diagram (3 of 4)
Go to component -> Cooling fan circuit, w/o trailer tow (1 of 2) -> ECU MODE
ecu mode wiring diagram (4 of 4)
ACTIVE GRILLE SHUTTER
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU WIRE
BRN WIRE
COOLING FAN MOTOR 1
COOLING FAN MOTOR 2
ECU MODE
ENGINE COOLING FAN RESISTOR 2
FUSE 18
FUSE 34
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ PCM POWER RELAY ENERGIZED
ORG/ WIRE
RED WIRE
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Cooling fan circuit, w/ trailer tow (1 of 2) -> ECU MODE
