Lincoln MKC I facelift (2018-2019) demand lp/ battery save relay Wiring diagrams
This page contains all the electrical diagrams for the component. demand lp/ battery save relay, in which he is found in the car Lincoln MKC I facelift (2018-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
demand lp/ battery save relay wiring diagram (1 of 2)
BACK LTG LED (FET)
BLK/BLU WIRE
BODY CONTROL MODULE (BCM)
BRN/VIO WIRE
DEMAND LP PWR
DEMAND LP/ BATTERY SAVE RELAY
FUSE 1
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/VIO WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
INTERIOR LIGHTING (FET)
M/ROOF CLOSE
M/ROOF OPEN
M/ROOF TILT
MEGA FUSE 10
MICRO -
OVERHEAD CONSOLE
POWER TOPS SYSTEM
RED WIRE
SBC
SHADE CLOSE
SHADE OPEN
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Overhead console circuit -> DEMAND LP/ BATTERY SAVE RELAY
demand lp/ battery save relay wiring diagram (2 of 2)
2.0L TURBO
BACK LTG (FET)
BATTERY JUNCTION BOX (BJB)
BSI (FET)
DEMAND LP/ BATTERY SAVE RELAY
ECU DRIVE (PCM WAKEUP) (FET)
EVAP VAPOR BLOCKING VALVE
EVAPORATIVE EMISSION (EVAP) PURGE VALVE
EVAPORATIVE EMISSION CANISTER VENT VALVE
FROM FUSE 23 (DIAGRAM 1 OF 9)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 9)
FUSE 1
FUSE 12
FUSE 26
FUSE 32
FUSE 33
GRN WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/YEL WIRE
INT LTG (FET)
LR STOP POS LPS (FET)
NCA WIRE
PARK LPS (FET)
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
REAR FOG LPS (FET)
RF DRL LPS (FET)
RF FOG LPS (FET)
RF HI BEAM (FET)
RF LO BEAM (FET)
RF POS LP (FET)
RF TURN LP (FET)
RR STOP POS LPS (FET)
RR TURN LP (FET)
TO FUSE 18 (DIAGRAM 7 OF 9)
TO FUSE 34 (DIAGRAM 7 OF 9)
WHITE LIGHT (FET)
WHT/BRN WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 9) -> DEMAND LP/ BATTERY SAVE RELAY
