Lincoln Mark I (1992-1998) control switch input wiring diagram
This page shows the only wiring diagram for the component.control switch input, which is found in the car Lincoln Mark I (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
control switch input wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER 14
CONTROL SWITCH INPUT
GROUND
HOT IN ACCY OR RUN
I/P FUSE PANEL
LEFT FRONT WINDOW MOTOR
LT BLU WIRE
LT LT
MASTER WINDOW CONTROL SWITCH
NCA WIRE
ONE TOUCH WINDOW DOWN MODULE
RED WIRE
RED/BLK WIRE
RED/LT BLU WIRE
RIGHT FRONT WINDOW MOTOR
RIGHT FRONT WINDOW SWITCH
SWITCH ILLUM.
TAN WIRE
UP DOWN
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> CONTROL SWITCH INPUT
