Base radio circuit for Lincoln LS I facelift (2003-2006)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT VPWR 1 2 3 4 5 6 SCP (+) 13 14 (NOT USED) ACP A ACP B ANTENNA AUDIO UNIT BATTERY JUNCTION BOX (BJB) (IN LUGGAGE COMPARTMENT, NEAR BATTERY) BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE CENTRAL JUNCTION COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM ELECTRONIC HIDDEN ANTENNA MODULE (EHAM) (ON REAR CENTER OF ROOF) FUSE 18 FUSE 2 BOX (CJB) (BEHIND RIGHT KICK PANEL) FUSE 27 FUSE 5 GRN WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR ACC HOT WITH SSP 3 RELAY ENERGIZED ILLUMINATION INTERIOR AUXILIARY JUNCTION BOX (AJB) (UNDER LEFT SIDE OF DASH) LEFT FRONT SPEAKER LEFT REAR SPEAKER MEM DN MEM UP MEDIA MUTE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE PARKING AID MODULE (PAM) (ON LEFT REAR OF PACKAGE TRAY) POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPARTMENT) RED WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER SCP+ SIG RTN STEERING WHEEL AUXILIARY AUDIO CONTROLS TWISTED PAIR VOLUME DN VOLUME UP VPWR VREF SIG RTN MUTE L FRONT SPKR (-) L REAR SPKR (-) R REAR SPKR (-) WHT WIRE WHT/BLK WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE
