Body control modules circuit for Lincoln LS I facelift (2003-2006)

BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SYSTEM ANTI-THEFT SYSTEM DOOR LOCKS SYSTEM ELECTRONIC POWER STEERING SYSTEM ELECTRONIC POWER STEERING SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM FRONT ELECTRONIC MODULE (FEM) (ON LEFT KICK PANEL) FUSE 20 FUSE 29 FUSE 30 FUSE 33 GRN WIRE GRY WIRE GRY/RED WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN HOT W/ SSP 2 RELAY ENERGIZED MEMORY SYSTEMS MEMORY SYSTEMS, SEATS SYSTEM MIRRORS SYSTEM ORG/ WIRE ORG/BLK WIRE ORG/GRN WIRE ORG/WHT WIRE ORG/YEL WIRE PNK WIRE PNK/ORG WIRE POWER DISTRIBUTION SYSTEM EXTERIOR LIGHTS SYSTEM RUN WIRE SEATS SYSTEM SEATS SYSTEM INTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM SEATS SYSTEM TO REAR ELECTRONIC MODULE (REM) (DIAGRAM 2 OF 2) TRUNK, TAILGATE, FUEL DOORS SYSTEM SEATS SYSTEMS VIO/BLU WIRE VIO/WHT WIRE W/ PARKING AID WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/VIO WIRE

BATTERY JUNCTION BOX (BJB) (IN LUGGAGE COMPARTMENT, NEAR BATTERY) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DOOR LOCKS SYSTEM ENGINE CONTROL SYSTEM ENGINE CONTROLS SYSTEM EXTERIOR LIGHTS SYSTEM WARNING SYSTEMS ANTI-THEFT SYSTEM FROM FROM FRONT ELECTRONIC MODULE (FEM) (DIAGRAM 1 OF 2) FUSE 1 FUSE 19 FUSE 30 GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/SSP 4 RELAY ENERGIZED MIRRORS SYSTEM POWER WINDOWS SYSTEM ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM POWER WINDOWS SYSTEM ENGINE CONTROLS SYSTEM POWER WINDOWS SYSTEM REAR ELECTRONIC MODULE (REM) (IN RIGHT SIDE OF LUGGAGE COMPARTMENT) RED WIRE RED/ORG WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO/BLU WIRE VIO/WHT WIRE WARNING SYSTEMS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/GRN WIRE YEL/RED WIRE
