Lincoln LS I (1999-2002) Charging circuit

AUXILIARY JUNCTION BOX (INTERIOR) (UNDER LEFT SIDE OF DASH) BATTERY BATTERY JUNCTION BOX (IN LUGGAGE COMPARTMENT, NEAR BATTERY) FUSE 415 BLK WIRE BLU WIRE BRN WIRE CENTRAL JUNCTION BOX (BEHIND RIGHT KICK PANEL) FUSE 217 GENERATOR GRN/BLK WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER JOINT CONNECTOR 4 (BEHIND LEFT SIDE OF DASH) POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPARTMENT) RED WIRE RED/BLU WIRE STARTER MOTOR STUD DASH PANEL (RIGHT FRONT WHEELWELL) VIO WIRE WHT WIRE WHT/RED WIRE
