Front heated seats circuit, w/o ventilation for Lincoln Corsair I (2019-2024)
Front heated seats circuit, w/o ventilation
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLU/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRV HEATER FEED
DRV HTR FEED
DRV SEAT NTC SENSE
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 39
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE (CENTER OF DASH)
LEFT FRONT SEAT BACKREST HEATER MAT
LEFT FRONT SEAT CUSHION HEATER MAT
MS CAN +
NCA WIRE
PASS HEATER FEED
PASS HTR FEED
PASS SEAT NTC SENSE
RIGHT END OF DASH)
RIGHT FRONT SEAT BACKREST HEATER MAT
RIGHT FRONT SEAT CUSHION HEATER MAT
SIG RTN
VIO/ORG WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
