Parking assistant circuit, w/o 360 view for Lincoln Corsair I (2019-2024)
Parking assistant circuit, w/o 360 view
BLK/BLU WIRE
BLK/GRY WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CAMERA ENABLE
COMPUTER DATA LINES SYSTEM
DRV ASSIST HOT KEY
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 8
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT W/ RUN/START RELAY ENERGIZED
HVAC CONTROL MODULE
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY
LEFT REAR INNER PARKING AID SENSOR
LEFT REAR OUTER PARKING AID SENSOR
LR INNER SNS
LR OUTER SNS
PARK AID
PARKING AID MODULE (PAM)
RIGHT REAR INNER PARKING AID SENSOR
RIGHT REAR OUTER PARKING AID SENSOR
RR INNER SNS
RR OUTER SNS
SIG RTN
SOLID STATE
VIO/GRY WIRE
VPWR
VREF
WHT/ORG WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
