Blind spot information system circuit for Lincoln Corsair I (2019-2024)
Blind spot information system circuit
BATTERY JUNCTION BOX (BJB)
BLIS LED -
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR
DRIVER DOOR MODULE (DDM)
FUSE 14
FUSE 25
FUSE 7
GRN/WHT WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LEFT EXTERIOR MIRROR
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SODL)
MS CAN +
NCA WIRE
PASSENGER DOOR MODULE (PDM)
RIGHT EXTERIOR MIRROR
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR)
VBATT
VIO/ORG WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/VIO WIRE
