Lincoln Corsair I (2019-2024) Ground distribution circuit

2.0L TURBO, 2.3L TURBO 2.5L PLUG-IN HYBRID ACTIVE GRILLE SHUTTER ADAPTIVE FRONT LIGHTING RELAY AIR CONDITIONING (A/C) COMPRESSOR AIR CONDITIONING CONTROL MODULE (ACCM) ANTI-THEFT HOOD SWITCH AUXILIARY COOLANT PUMP AWD RELAY BATTERY JUNCTION BOX (BCMC) BATTERY JUNCTION BOX (BJB) BLK WIRE BLOWER MOTOR RELAY BLUETOOTH ANTENNA 11 BRAKE PEDAL POSITION (BPP) SWITCH CABIN COOLANT HEATER CHARGE STATUS INDICATOR (CSI) COOLANT PUMP RELAY COOLING FAN RELAY CRUISE CONTROL MODULE (CCM) ENGINE COOLANT BYPASS VALVE EVAC, FILL FRONT EVAPORATOR SHUTOFF VALVE (FESOV) GRN WIRE GRY WIRE HIGH VOLTAGE BATTERY CHILLER SHUTOFF VALVE (CHSOV) HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE HIGH VOLTAGE BATTERY COOLANT PUMP LEFT FRONT FOG LAMP LEFT FRONT SIDE MARKER LAMP LEFT HEADLAMP ASSEMBLY LEFT HORN LOW WASHER FLUID WARNING INDICATOR SWITCH MULTI- CONTOUR SEATS RELAY REAR WASHER RELAY REMOTE KEYLESS ENTRY (RKE) EXTERIOR SOUNDER RIGHT FRONT FOG LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT HEADLAMP ASSEMBLY RIGHT HORN SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE C (SOBDMC) TRANSMISSION FLUID PUMP WINDSHIELD WIPER MOTOR

2.0L TURBO, 2.3L TURBO 2.5L PLUG-IN HYBRID ACTIVE TORQUE CONTROL COUPLING (ATCC) SOLENOID AUDIO CONTROL MODULE (ACM) BLK WIRE BLOWER MOTOR CONTROL MODULE BLU WIRE BODY CONTROL MODULE (BCM) CARGO LAMP CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY CHILD LOCK RELAY DOUBLE/AUX LOCK RELAY DRIVER/FUEL FLAP UNLOCK RELAY ELECTRIC MOTOR COOLANT PUMP FRONT CONTROLS INTERFACE MODULE (FCIM) FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE SHIELD GATEWAY MODULE (GWM) GLOVE COMPARTMENT LAMP GRN WIRE GRY WIRE HANDS FREE ACTUATION MODULE HIGH MOUNTED STOP LAMP HVAC CONTROL MODULE HYBRID INTEGRATED SYSTEM CONTROLLER (ISC) MODULE IMAGE PROCESSING MODULE B (IPMB) LEFT REAR LAMP ASSEMBLY LIFTGATE LATCH/UNLATCH ASSEMBLY MICRO - NCA WIRE PEDESTRIAN ALERT CONTROL MODULE (PACM) POWER LIFTGATE SWITCH POWER STEERING CONTROL MODULE (PSCM) REAR WINDOW DEFROST GRID REAR WINDOW WIPER MOTOR REMOTE FUNCTION ACTUATOR (RFA) MODULE RIGHT END OF DASH) RIGHT REAR LAMP ASSEMBLY RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SODR) SECOND ROW FOLDING SEAT SWITCH SYNC MODULE (APIM) TELEMATICS CONTROL UNIT (TCU) MODULE TRANSMISSION SENSOR SPEED RESOLVER VEHICLE DYNAMICS MODULE (VDM) VIO WIRE W/ BLUETOOTH WHT WIRE WIRELESS ACCESSORY CHARGING MODULE (WACM)

ALL TERRAIN CONTROL MODULE (ATCM) AUTO DIMMING INTERIOR MIRROR BATTERY ENERGY CONTROL MODULE B (BECMB) BLK WIRE BLK/BLU WIRE BLU WIRE CLOCKSPRING DOWNSHIFT PADDLE SWITCH ELECTRONIC PARK BRAKE SWITCH FLOOR CONSOLE STORAGE BIN AMBIENT LIGHTING LAMP FRONT CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP FRONT MEDIA BIN AMBIENT LED GATEWAY MODULE (GWM) GEAR SHIFT MODULE (GSM) GRN WIRE HEAD-UP DISPLAY HEAD-UP DISPLAY (HUD) MODULE HEADLAMP CONTROL MODULE (HCM) HORN SWITCH IMAGE PROCESSING MODULE A (IPMA) INSTRUMENT PANEL CLUSTER (IPC) MODULE INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY LEFT FOOTWELL LAMP LEFT INTERIOR/MAP LAMPS ASSEMBLY LEFT VANITY MIRROR LAMP MEDIA BIN AMBIENT LED MEDIA BIN POWER OUTLET SOCKET MULTI- FUNCTION SWITCH NCA WIRE OVERHEAD CONSOLE PASSENGER SIDE INSTRUMENT PANEL AMBIENT LIGHTING LAMP PUSH BUTTON START IGNITION SWITCH RADIO TRANSCEIVER MODULE (RTM) RAIN SENSOR REAR HEATED SEAT SWITCH RIGHT FOOTWELL LAMP RIGHT INTERIOR/MAP LAMPS ASSEMBLY RIGHT VANITY MIRROR LAMP STEERING COLUMN CONTROL MODULE (SCCM) UPSHIFT PADDLE SWITCH USB CHARGE PORT 1 USB CHARGE PORT 2 W/ AMBIENT LIGHTING W/ REAR HEATED SEATS WHT WIRE

ACTIVE TORQUE CONTROL COUPLING (ATCC) SOLENOID SHIELD BLK WIRE BLUETOOTH ANTENNA 3 BLUETOOTH ANTENNA 4 DRIVER DOOR MODULE (DDM) DRIVER DOOR WINDOW SWITCH GRN WIRE GRY WIRE KEYPAD SWITCH ASSEMBLY LEFT FRONT DOOR LATCH LEFT FRONT EXTERIOR DOOR HANDLE LEFT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP LEFT SEAT ADJUST SWITCH NCA WIRE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) PASSENGER DOOR MODULE (PDM) PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH) PASSENGER SEAT MODULE (PSM) POWER TRANSFER UNIT (PTU) SHIELD RIGHT FRONT EXTERIOR DOOR HANDLE RIGHT FRONT INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP RIGHT FRONT SCUFF PLATE LAMP RIGHT FRONT SEAT AMBIENT LIGHTING LAMP RIGHT FRONT SEAT BACKREST HEATER MAT RIGHT FRONT SEAT BELT BUCKLE RIGHT FRONT SEAT POSITION SENSOR RIGHT MULTI-CONTOUR CONTROL PUMP RIGHT REAR DOOR LATCH RIGHT REAR EXTERIOR DOOR HANDLE RIGHT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP RIGHT SEAT ADJUST SWITCH RIGHT SECOND ROW SEAT BACKREST HEATER MAT RIGHT SECOND ROW SEAT RELEASE EASY ENTRY MOTOR VIO WIRE W/ BLUETOOTH W/ HEATED SEATS W/ REAR HEATED SEATS WHT WIRE

AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) BLK WIRE BLUETOOTH ANTENNA 1 BLUETOOTH ANTENNA 2 BLUETOOTH ANTENNA 7 DECKLID RELEASE SWITCH/LAMP ASSEMBLY DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) DRIVER SEAT MODULE (DSM) GRY WIRE LEFT FRONT SCUFF PLATE LAMP LEFT FRONT SEAT AMBIENT LIGHTING LAMP LEFT FRONT SEAT BACKREST HEATER MAT LEFT MULTI-CONTOUR CONTROL PUMP LEFT REAR DOOR LATCH LEFT REAR EXTERIOR DOOR HANDLE LEFT REAR INTERIOR DOOR HANDLE AMBIENT LIGHTING LAMP LEFT REAR LAMP ASSEMBLY LEFT SECOND ROW SEAT BACKREST HEATER MAT LEFT SECOND ROW SEAT RELEASE EASY ENTRY MOTOR LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SODL) LUGGAGE COMPARTMENT POWER OUTLET SOCKET NCA WIRE PARKING AID MODULE (PAM) REAR GATE TRUNK MODULE (RGTM) REAR HEATED SEAT MODULE REAR LAMP FADE CONTROL MODULE RIGHT REAR LAMP ASSEMBLY ROOF OPENING PANEL MODULE SUBWOOFER AMPLIFIER VIO WIRE W/ BLUETOOTH W/ HARMAN REVEL W/ HEATED SEATS W/ REAR HEATED SEATS YEL WIRE

2.0L TURBO, 2.3L TURBO 2.5L PLUG-IN HYBRID ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY BATTERY ENERGY CONTROL MODULE (BECM) BLK WIRE BLU WIRE CABIN COOLANT HEATER CHARGE PORT COOLING FAN MOTOR EXCEPT 2.5L PLUG-IN HYBRID FUEL PUMP CONTROL MODULE FUEL PUMP, SENDER UNIT SHIELD GRN WIRE HEATED WIPER PARK IGNITION COIL ON PLUG 1 IGNITION COIL ON PLUG 2 IGNITION COIL ON PLUG 3 IGNITION COIL ON PLUG 4 NCA WIRE POWERTRAIN CONTROL MODULE (PCM) SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM) VIO WIRE WHT WIRE YEL WIRE
