Electronic power steering circuit for Lincoln Corsair I (2019-2024)
Electronic power steering circuit
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLU/RED WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
FUSE 2
FUSE 22
GRN/BLU WIRE
GRN/ORG WIRE
GRY/BLU WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC) MODULE
MOTOR
POWER STEERING CONTROL MODULE (PSCM)
PWR GND
VBATT
VPWR
WHT/GRN WIRE
