Lincoln Continental X (2016-2024) Ground distribution circuit

2.7L TURBO, 3.0L TURBO 3.7L ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY BATTERY CURRENT SENSOR BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE COIL ON PLUG (COP) 1 COIL ON PLUG (COP) 2 COIL ON PLUG (COP) 3 COIL ON PLUG (COP) 4 COIL ON PLUG (COP) 5 COIL ON PLUG (COP) 6 ENDS IN HARNESS (BLUNT CUT) LEFT HEADLAMP ASSEMBLY LEFT HEATED WINDSHIELD ELEMENT LEFT HORN LOW WASHER FLUID WARNING INDICATOR SWITCH NCA WIRE POWER STEERING CONTROL MODULE (PSCM) POWERTRAIN CONTROL MODULE (PCM) RIGHT HEADLAMP ASSEMBLY RIGHT HEATED WINDSHIELD ELEMENT RIGHT HORN TOP OF ENGINE) TRANSMISSION RANGE CONTROL MODULE (TRCM) W/ HID W/O HID

ACTIVE GRILLE SHUTTER AIR CONDITIONING (A/C) COMPRESSOR AIR QUALITY SENSOR ANTI- THEFT HORN BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BRAKE PEDAL POSITION (BPP) SWITCH CRUISE CONTROL MODULE (CCM) ENDS IN HARNESS (BLUNT CUT) EXTERIOR SOUNDER FRONT BLOWER MOTOR RELAY FRONT MULTI- CONTOUR SEATS (MCS) RELAY HEADLAMP WASHER PUMP HOOD AJAR SWITCH LEFT COOLING FAN MOTOR LEFT HEADLAMP ASSEMBLY LOW BRAKE FLUID WARNING INDICATOR SWITCH REAR BLOWER MOTOR RELAY RELAY MODULE REAR MULTI- CONTOUR SEATS (MCS) RELAY TORQUE VECTORING RELAY TRANSFER CASE COOLANT PUMP W/ HID W/O HID WINDSHIELD WASHER PUMP WINDSHIELD WIPER MOTOR

BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE CENTER CONSOLE CLOCKSPRING CLOCKSPRING/ STEERING ANGLE SENSOR MODULE (SASM) COLUMN, PEDAL MEMORY MODULE (BCMB) COMPACT DISC PLAYER CONSOLE POWER POINT DOWNSHIFT PADDLE SWITCH ENDS IN HARNESS FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP FLOOR CONSOLE STORAGE BIN AMBIENT LIGHTING LAMP FRONT CIGAR LIGHTER GATEWAY MODULE DATA LINK CONNECTOR (DLC) GEAR SHIFT MODULE (GSM) HEAD-UP DISPLAY (HUD) MODULE HEADLAMP CONTROL MODULE (HCM) HEADLAMP SWITCH HEATED STEERING WHEEL MODULE HORN SWITCH IMAGE PROCESSING MODULE B (IPMB) INSTRUMENT PANEL CLUSTER (IPC) INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY LEFT FLOOR CONSOLE TRIM AMBIENT LIGHTING LEFT FOOTWELL LAMP LEFT STEERING WHEEL SWITCH MEDIA BIN AMBIENT LED NCA WIRE PARKING BRAKE SWITCH PASSENGER I/P LAMP PUSH BUTTON START IGNITION SWITCH REAR POWER POINT RIGHT FLOOR CONSOLE TRIM AMBIENT LIGHTING RIGHT FOOTWELL LAMP RIGHT STEERING WHEEL SWITCH SHIFT INTERLOCK OVERRIDE SWITCH STEERING COLUMN CONTROL MODULE (SCCM) STEERING COLUMN) STEERING EFFORT CONTROL MODULE (SECM) SYNC MODULE (APIM) UPSHIFT PADDLE SWITCH W/ ADAPTIVE STEERING W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING

3.0L TURBO BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR CONTROL MODULE CENTER CONSOLE DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER ENDS IN HARNESS FRONT CONTROLS INTERFACE MODULE (FCIM) FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE 2 FUEL PUMP SHIELD GLOVE COMPARTMENT LAMP HAZARD FLASHER SWITCH LEFT REAR INTERIOR/ MAP LAMPS ASSEMBLY LEFT VANITY MIRROR LAMP NCA WIRE OVERHEAD CONSOLE REAR BLOWER MOTOR REAR CLIMATE CONTROL SEAT MODULE REAR HEATED SEAT SWITCH RIGHT FRONT SCUFF PLATE LAMP RIGHT REAR FOOTWELL LAMP RIGHT REAR INTERIOR/ MAP LAMPS ASSEMBLY RIGHT REAR SCUFF PLATE TRIM PANEL RIGHT REAR SEAT ADJUST SWITCH RIGHT VANITY MIRROR LAMP USB CHARGE PORT W/ REAR SEAT CONTROLS

BLK/GRY WIRE DRIVER DOOR DRIVER DOOR MODULE (DDM) KEYLESS ENTRY KEYPAD LEFT EXTERIOR MIRROR LEFT FRONT DOOR CONTROL MODULE LEFT FRONT DOOR LOCK SWITCH LEFT FRONT DOOR TWEETER SPEAKER LEFT FRONT EXTERIOR DOOR LATCH LOCK SWITCH LEFT FRONT EXTERIOR DOOR LATCH SWITCH LEFT FRONT INTERIOR DOOR LATCH SWITCH LEFT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP LEFT INTERIOR REAR DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP LEFT REAR DOOR CONTROL MODULE LEFT REAR DOOR LOCK SWITCH LEFT REAR DOOR MODULE (RDM) LEFT REAR DOOR TWEETER SPEAKER LEFT REAR EXTERIOR DOOR LATCH SWITCH LEFT REAR INTERIOR DOOR LATCH SWITCH LEFT REAR SEAT ADJUST SWITCH LEFT SEAT ADJUST SWITCH NCA WIRE ROOF OPENING PANEL MODULE

BATTERY ENERGY CONTROL MODULE B (BECMB) BLK/WHT WIRE CENTER CONSOLE NCA WIRE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) PASSENGER DOOR MODULE (PDM) PASSENGER DOOR) PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH) PASSENGER SAFETY BELT BUCKLE PASSENGER SEAT MODULE (PSM) RIGHT EXTERIOR MIRROR RIGHT FRONT DOOR CONTROL MODULE RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT DOOR TWEETER SPEAKER RIGHT FRONT EXTERIOR DOOR LATCH LOCK SWITCH RIGHT FRONT EXTERIOR DOOR LATCH SWITCH RIGHT FRONT INTERIOR DOOR LATCH SWITCH RIGHT FRONT SEAT BACKREST HEATER RIGHT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP RIGHT INTERIOR REAR DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP RIGHT MULTI-CONTOUR CONTROL PUMP RIGHT REAR DOOR RIGHT REAR DOOR CONTROL MODULE RIGHT REAR DOOR LOCK SWITCH RIGHT REAR DOOR MODULE (RDM) RIGHT REAR DOOR TWEETER SPEAKER RIGHT REAR EXTERIOR DOOR LATCH SWITCH RIGHT REAR INTERIOR DOOR LATCH SWITCH RIGHT REAR SEAT ADJUST SWITCH RIGHT SEAT ADJUST SWITCH RIGHT SEAT POSITION SENSOR W/ REAR SEAT CONTROLS

AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) AUDIO FRONT CONTROL MODULE (ACM) AUTO DIMMING INTERIOR MIRROR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY CHILD LOCK RELAY DECKLID RELAY DOUBLE/ AUX LOCK RELAY DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) DRIVER SEAT MODULE (DSM) DRIVER/ FUEL FLAP UNLOCK RELAY ENDS IN HARNESS ENDS IN HARNESS (BLUNT CUT) GRY WIRE INTRUSION SENSOR LEFT FRONT SCUFF PLATE LAMP LEFT FRONT SEAT BACKREST HEATER LEFT MULTI-CONTOUR CONTROL PUMP LEFT REAR FOOTWELL LAMP LEFT REAR SCUFF PLATE TRIM PANEL LEFT REAR SEAT ADJUST SWITCH MICRO - NCA WIRE RADIO TRANSCEIVER MODULE (RTM) RAIN SENSOR MODULE SUBWOOFER AMPLIFIER W/ HARMAN REVEL ULTIMA AUDIO SYSTEM W/ REAR SEAT CONTROLS W/ START/ STOP W/O HARMAN REVEL ULTIMA AUDIO SYSTEM W/O START /STOP

ALL WHEEL DRIVE (AWD) MODULE ALL-WHEEL DRIVE (AWD) RELAY MODULE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLUNT CUT 440 (ENDS IN HARNESS) BLUNT CUT 441 (ENDS IN HARNESS) BLUNT CUT 442 (ENDS IN HARNESS) DECKLID LAMP ASSEMBLY ENDS IN HARNESS (BLUNT CUT) HANDSFREE LUGGAGE COMPARTMENT LID ACTUATION MODULE HIGH MOUNTED STOP LAMP LEFT REAR AFT RELAY LEFT REAR FORWARD RELAY LEFT REAR LAMP ASSEMBLY LEFT REAR MULTI-CONTOUR SEAT CONTROL PUMP LEFT REAR MULTI-CONTOUR SEAT MODULE (SCMC) LEFT REAR POWER FOLD HEADREST MOTOR LEFT REAR SEAT BACKREST HEATER LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) LUGGAGE COMPARTMENT LID CONTROL SWITCH LUGGAGE COMPARTMENT LID LATCH LUGGAGE COMPARTMENT LID POWER STRIKER LUGGAGE COMPARTMENT LID POWER STRIKER ASSEMBLY NCA WIRE POWER DECKLID MOTOR REAR AUDIO CONTROL MODULE (RACM) REAR CLIMATE CONTROL SEAT SWITCH REAR DUAL CLIMATE CONTROLLED SEAT MODULE (DCSM) REAR GATE TRUNK MODULE (RGTM) REAR HEATED SEAT MODULE REAR LAMP FADE CONTROL MODULE REAR WINDOW BLIND MODULE RIGHT REAR AFT RELAY RIGHT REAR FORWARD RELAY RIGHT REAR LAMP ASSEMBLY RIGHT REAR MULTI-CONTOUR SEAT CONTROL PUMP RIGHT REAR MULTI-CONTOUR SEAT MODULE (SCMD) RIGHT REAR POWER FOLD HEADREST MOTOR RIGHT REAR SEAT BACKREST HEATER RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) TELEMATIC CONTROL UNIT (TCU) MODULE VEHICLE DYNAMICS MODULE (VDM)
