Lincoln Continental X (2016-2024) presented mtr wiring diagram
This page shows the only wiring diagram for the component.presented mtr, which is found in the car Lincoln Continental X (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
presented mtr wiring diagram (1 of 1)
AJAR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/WHT WIRE
CAN (+)
CINCHED MTR
CINCHED SW A
COMPUTER DATA LINES SYSTEM
DECKLID
DECKLID LAMP ASSEMBLY
DECKLID RELAY
EXT SW
FUSE 16
FUSE 57
GND STRIKER UP SW
GRN/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
IP RELEASE
LAMP
LUGGAGE COMPARTMENT LID LATCH
LUGGAGE COMPARTMENT LID POWER STRIKER ASSEMBLY
LUGGAGE COMPARTMENT LID RELEASE SWITCH
MEGA FUSE 1
MICRO -
MOTOR
NCA WIRE
PRESENTED MTR
PRESENTED SW B
RED WIRE
STRIKER DN SW
VBATT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Trunk release circuit, w/o power decklid -> PRESENTED MTR
