Lincoln Continental X (2016-2024) override sw 2 Wiring diagram
This page shows the only wiring diagram for the component.override sw 2, which is found in the car Lincoln Continental X (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram override sw 2 (1 of 1)
2.7L TURBO, 3.0L TURBO
3.7L
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/BLU WIRE
BSI (FET)
BTSI
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOOR STATUS
FUSE 12
FUSE 50
FUSE 91
GEAR SHIFT MODULE (GSM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
MICRO -
OS 1
OS 2
OVERRIDE SW 1
OVERRIDE SW 2
POWERTRAIN CONTROL MODULE (PCM)
PWM 1
PWM 2
PWM 3
RELAY MODULE
SHIFT INTERLOCK OVERRIDE SWITCH
TR 1
TR 2
TR 3
TR 4
TR GND
TRANSMISSIONS SYSTEM
TRS
TSS/OSS/ TR GND
VBATT
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Shift interlock circuit -> OVERRIDE SW 2
