Lincoln Continental X (2016-2024) outside lock sw Wiring diagrams

This page contains all the electrical diagrams for the component. outside lock sw, in which he is found in the car Lincoln Continental X (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram outside lock sw (1 of 2)

Wiring diagram outside lock sw for Lincoln Continental X (2016-2024) (1 of 2)

Get access

ALL LOCK/ BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CINCH COMPUTER DATA LINES SYSTEM DRIVER DOOR DRIVER DOOR MODULE (DDM) DRIVER UNLOCK FL CAP SNS LF DOOR DATA AJAR FUSE 25 FUSE 89 GEAR SHIFT MODULE (GSM) GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES ILLUM LEDS LEFT FRONT DOOR CINCH MOTOR LEFT FRONT DOOR CONTROL MODULE (DRIVER DOOR) LEFT FRONT DOOR LOCK SWITCH LEFT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP LEFT SEAT ADJUST SWITCH LF AJAR LK STATUS RTN LOCK LOCK IND LOCK RPTR MICRO - MS CAN + OUT UNLATCH RTN OUT UNLATCH(NC) OUT UNLATCH(NO) OUTSIDE LOCK SW PEPS TELEGRAM RED WIRE RELAY MODULE UNLOCK UNLOCK RPTR UNLOCK RPTR LOCK RPTR VBATT VIO WIRE VIO/GRY WIRE VIO/ORG WIRE WHT/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

Go to component -> Anti-theft circuit (1 of 8) -> OUTSIDE LOCK SW

Wiring diagram outside lock sw (2 of 2)

Wiring diagram outside lock sw for Lincoln Continental X (2016-2024) (2 of 2)

Get access

Go to component -> Power door locks circuit (1 of 8) -> OUTSIDE LOCK SW
