Lincoln Continental X (2016-2024) led sns Wiring diagrams

This page contains all the electrical diagrams for the component. led sns, in which he is found in the car Lincoln Continental X (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram led sns for Lincoln Continental X (2016-2024) (1 of 4)

Get access

ANODE BATTERY JUNCTION BOX (BJB) BIN SNS BIN/NTC BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/GRN WIRE BRN/VIO WIRE CATHODE GND COMPUTER DATA LINES SYSTEM DRL/NTC- DRL/PARK- FUSE 20 FUSE 48 FUSE 95 GND (HEADLAMP LEVELING) GRY/VIO WIRE HEADLAMP CONTROL MODULE (HCM) (LEFT SIDE OF DASH) HI BEAM HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LED SNS LEFT DAYTIME RUNNING LAMP (DRL) LEFT HEADLAMP ASSEMBLY LF HI BEAM (FET) LF LOW BEAM (FET) LF PARK/ FOG LP (FET) LIN 06 LIN LEFT LIN RIGHT LOW BEAM MICRO - NCA WIRE NTC SNS PARK/FOG RELAY MODULE SHIELD TURN VIO/GRN WIRE VIO/RED WIRE VPWR VPWR BALLAST VPWR MOTOR (HEADLAMP LEVELING) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Headlights circuit, w/ high intensity gas discharge headlights (1 of 3) -> LED SNS

Wiring diagram led sns for Lincoln Continental X (2016-2024) (2 of 4)

Get access

ANODE BATTERY JUNCTION BOX (BJB) BIN SNS BIN/NTC BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/BRN WIRE BLU/ORG WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/RED WIRE BRN/YEL WIRE CATHODE GND DRL/NTC- DRL/PARK- FUSE 30 FUSE 50 FUSE 94 GND (HEADLAMP LEVELING) GRN/VIO WIRE GRY/BLU WIRE HI BEAM HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LED SNS LIN 1 LOW BEAM MICRO - NTC SNS PARK/FOG REAR FOG LPS (FET) RELAY MODULE RF HI LP (FET) RF LOW LP (FET) RF PARK/ FOG LP (FET) RIGHT DAYTIME RUNNING LAMP (DRL) RIGHT HEADLAMP ASSEMBLY TURN VIO WIRE VIO/GRY WIRE VPWR BALLAST VPWR MOTOR (HEADLAMP LEVELING) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE

Go to component -> Headlights circuit, w/ high intensity gas discharge headlights (2 of 3) -> LED SNS

Wiring diagram led sns for Lincoln Continental X (2016-2024) (3 of 4)

Get access

ANODE BATTERY JUNCTION BOX (BJB) BIN SNS BIN/NTC BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE CATHODE GND COMPUTER DATA LINES SYSTEM DRL/NTC- DRL/PARK- FUSE 20 FUSE 48 GND (HEADLAMP LEVELING) GRY/BRN WIRE HEADLAMP CONTROL MODULE (HCM) HI BEAM HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LED SNS LEFT DAYTIME RUNNING LAMP (DRL) LEFT HEADLAMP ASSEMBLY LF HI BEAM (FET) LF LED LF LED TURN OUTAGE LF LOW BEAM (FET) LF PARK/ FOG LP (FET) LIN 06 LIN 1 LIN LEFT LIN RIGHT LOW BEAM MICRO - NCA WIRE NTC SNS OUTAGE PARK/FOG SHIELD TURN VIO/GRN WIRE VIO/RED WIRE VPWR VPWR MOTOR (HEADLAMP LEVELING) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component -> Headlights circuit, w/o high intensity gas discharge headlights (1 of 3) -> LED SNS

Wiring diagram led sns for Lincoln Continental X (2016-2024) (4 of 4)

Get access

ANODE BATTERY JUNCTION BOX (BJB) BIN SNS BIN/NTC BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/YEL WIRE CATHODE GND DRL/NTC- DRL/PARK- FUSE 30 FUSE 50 GRN/VIO WIRE GRY/BLU WIRE HI BEAM HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LED SNS LIN 1 LIN GND (HEADLAMP LEVELING) LOW BEAM MICRO - NTC SNS OUTAGE PARK/FOG REAR FOG LPS (FET) RF HI LP (FET) RF LOW LP (FET) RF PARK/ FOG LP (FET) RIGHT DAYTIME RUNNING LAMP (DRL) RIGHT HEADLAMP ASSEMBLY TURN TURN OUTAGE VIO/GRY WIRE VIO/ORG WIRE VPWR MOTOR (HEADLAMP LEVELING) WHT WIRE WHT/BLU WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE

Go to component -> Headlights circuit, w/o high intensity gas discharge headlights (2 of 3) -> LED SNS

Lincoln Continental X (2016-2024) led sns Wiring diagrams

Wiring diagram led sns (1 of 4)

List of components:

Wiring diagram led sns (2 of 4)

List of components:

Wiring diagram led sns (3 of 4)

List of components:

Wiring diagram led sns (4 of 4)

List of components:
