Lincoln Continental X (2016-2024) drv strng col feed Wiring diagram
This page shows the only wiring diagram for the component.drv strng col feed, which is found in the car Lincoln Continental X (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv strng col feed (1 of 1)
ADAPTIVE STRNG FEED
ADAPTIVE STRNG RTN
BLU WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CENTER CONSOLE
CLOCKSPRING
COLLAPSIBLE STEERING COLUMN MODULE
DEPLOY STRNG COL FEED
DEPLOY STRNG COL RTN
DRIVER AIR BAG MODULE
DRIVER LOWER AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRT CR SN FEED
DRV FRT CR SN RTN
DRV STRNG COL FEED
DRV STRNG COL RTN
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
LEFT FRONT IMPACT SEVERITY SENSOR
NCA WIRE
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS FRT CR SN FEED
PASS FRT CR SN RTN
PASS STRNG COL FEED
PASS STRNG COL RTN
PASSENGER AIR BAG
PASSENGER LOWER AIR BAG
RESTRAINTS CONTROL MODULE (RCM)
SHORTING BAR
STAGE 1
STAGE 2
VBATT INPUT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
W/ ADAPTIVE STEERING
W/O ADAPTIVE STEERING
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> DRV STRNG COL FEED
