Lincoln Continental X (2016-2024) driver unlock Wiring diagrams
This page contains all the electrical diagrams for the component. driver unlock, in which he is found in the car Lincoln Continental X (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver unlock wiring diagram (1 of 2)
ALL LOCK/
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLU WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CINCH
COMPUTER DATA LINES SYSTEM
DRIVER DOOR
DRIVER DOOR MODULE (DDM)
DRIVER UNLOCK
FL CAP SNS LF DOOR DATA AJAR
FUSE 25
FUSE 89
GEAR SHIFT MODULE (GSM)
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
ILLUM
LEDS
LEFT FRONT DOOR CINCH MOTOR
LEFT FRONT DOOR CONTROL MODULE (DRIVER DOOR)
LEFT FRONT DOOR LOCK SWITCH
LEFT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LIGHTING LAMP
LEFT SEAT ADJUST SWITCH
LF AJAR
LK STATUS RTN
LOCK
LOCK IND
LOCK RPTR
MICRO -
MS CAN +
OUT UNLATCH RTN
OUT UNLATCH(NC)
OUT UNLATCH(NO)
OUTSIDE LOCK SW
PEPS TELEGRAM
RED WIRE
RELAY MODULE
UNLOCK
UNLOCK RPTR
UNLOCK RPTR LOCK RPTR
VBATT
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BLU WIRE
YEL/GRN WIRE
YEL/VIO WIRE
Go to component -> Anti-theft circuit (1 of 8) -> DRIVER UNLOCK
