Power lumbar seat circuit for Lincoln Continental IX (1995-2002)
Power lumbar seat circuit
BATTERY JUNCTION BOX (IN ENGINE COMPT, ABOVE LEFT WHEELWELL)
BLK WIRE
BRN WIRE
DK GRN WIRE
FUSE 1
FUSE 2
HOT AT ALL TIMES
LEFT FRONT 2-WAY POWER LUMBAR SWITCH
LEFT FRONT POWER LUMBAR MOTOR ASSEMBLY (UNDER FRONT OF SEAT)
PNK WIRE
RED WIRE
RIGHT FRONT 2-WAY POWER LUMBAR SWITCH
RIGHT FRONT POWER LUMBAR MOTOR ASSEMBLY (UNDER FRONT OF SEAT) (RIGHT KICK PANEL)
