Lincoln Continental IX (1995-2002) command sig command rtn ign wiring diagram
This page shows the only wiring diagram for the component.command sig command rtn ign, which is found in the car Lincoln Continental IX (1995-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
command sig command rtn ign wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 DATA LINE + DATA LINE -
120 OHMS
2200 OHMS
680 OHMS
914 915 COMPUTER DATA LINES
AIR BAG SLIDING CONTACT
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
BRK TRAVEL IN GRD
COAST
COMMAND SIG COMMAND RTN IGN
DK DK
FUSE 28
FUSE 32
FUSE 6
FUSE JUNCTION PANEL
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
HOT IN
LIGHTING CONTROL MODULE (LCM)
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/VIO WIRE
NCA WIRE
OFF
ORG/ WIRE
PNK/LT BLU WIRE
RED WIRE
RESUME
RUN WIRE
SET/ ACCEL
SPEED CONTROL DEAC SWITCH (BELOW DASH, NEXT TO BRAKE PEDAL POSITION SWITCH)
SPEED CONTROL SERVO (ON LEFT SHOCK TOWER)
SPEED CONTROL SWITCH ASSEMBLY
TAN/ORG WIRE
VIO WIRE
WHT WIRE
Go to component -> Cruise control circuit -> COMMAND SIG COMMAND RTN IGN
