Car Wiring Diagrams for Power windows circuit for Lincoln Aviator II (2019-2024)

BATTERY JUNCTION BOX (BCMC) BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE COMPUTER DATA LINES SYSTEM DEMAND LP/ BATT SAVE (FET) DRIVER DOOR MODULE (DDM) FUSE 109 FUSE 73 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES ILLUM LEFT FRONT DOOR WINDOW CONTROL SWITCH LEFT FRONT DOOR WINDOW REGULATOR MOTOR LEFT REAR DOOR WINDOW CONTROL SWITCH LEFT REAR DOOR WINDOW REGULATOR MOTOR LIN BUS MS CAN + PASSENGER DOOR MODULE (PDM) RED WIRE RIGHT FRONT DOOR WINDOW CONTROL SWITCH RIGHT FRONT DOOR WINDOW REGULATOR MOTOR) RIGHT REAR DOOR WINDOW CONTROL SWITCH RIGHT REAR DOOR WINDOW REGULATOR MOTOR VBATT VIO/ORG WIRE VIO/WHT WIRE VPWR WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE WINDOW DOWN WINDOW UP YEL/GRN WIRE YEL/ORG WIRE
