Parking assistant circuit, w/o 360 view for Lincoln Aviator II (2019-2024)
Parking assistant circuit, w/o 360 view (1 of 2)
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 36
GRN/BRN WIRE
GRN/WHT WIRE
HOT W/ RUN/START RELAY ENERGIZED
LEFT REAR INNER PARKING AID SENSOR
LEFT REAR OUTER PARKING AID SENSOR
LR INNER SNS
LR OUTER SNS
ORG/ WIRE
PARK ASSIST
PARKING ASSIST CONTROL MODULE (PAM)
POWER DISTRIBUTION SYSTEM
RIGHT REAR INNER PARKING AID SENSOR
RIGHT REAR OUTER PARKING AID SENSOR
RR INNER SNS
RR OUTER SNS
SIG RTN
SOLID STATE
VIO/GRY WIRE
VPWR
VREF
WHT/BLU WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Parking assistant circuit, w/o 360 view (2 of 2)
BLK/VIO WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BRN WIRE
INSTRUMENT PANEL SWITCH PACK
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
PARK ASSIST SWITCH
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
SOLID STATE
VIO/GRY WIRE
WHT/BLU WIRE
YEL/ORG WIRE
