Blind spot information system circuit for Lincoln Aviator II (2019-2024)
Blind spot information system circuit
BATTERY JUNCTION BOX (BCMC)
BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
BLIS INDICATOR
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDM)
FUSE 109
FUSE 25
FUSE 73
GRN/WHT WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY 2 ENERGIZED
LEDS
LEFT EXTERIOR MIRROR
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
MS CAN +
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MODULE (PDM)
POWER DISTRIBUTION SYSTEM
RED WIRE
RIGHT EXTERIOR MIRROR
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
SIG RTN
VBATT
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/VIO WIRE
