All around vision camera circuit for Lincoln Aviator II (2019-2024)
All around vision camera circuit
BLK WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BODY CONTROL MODULE (BCM)
COAX
COMPUTER DATA LINES SYSTEM
FRONT PARKING AID CAMERA
FRONT VIDEO +
FUSE 15
HOT AT ALL TIMES
IMAGE PROCESSING MODULE B (IPMB)
LEFT SIDE PARKING AID CAMERA
LEFT SIDE VIDEO
REAR PARKING AID CAMERA
REAR VIDEO -
RIGHT SIDE PARKING AID CAMERA
RIGHT SIDE VIDEO
SYNC MODULE (APIM) (CENTER OF DASH)
VBATT
VIDEO+
VIO/WHT WIRE
WHT/RED WIRE
