Ground distribution circuit for Lincoln Aviator II (2019-2024)

3.0L TURBO 3.0L TURBO HYBRID AIR CONDITIONING (A/C) CLUTCH, AIR CONDITIONING (A/C) CLUTCH FIELD COIL AIR CONDITIONING CONTROL MODULE (ACCM) ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BATTERY BATTERY JUNCTION BOX (BCMC) BATTERY MONITORING SENSOR BLK WIRE BLK/VIO WIRE BLU WIRE BLUETOOTH ANTENNA CABIN COOLANT HEATER CABIN HEATER COOLANT DIVERTER VALVE CABIN HEATER COOLANT PUMP CHARGE STATUS INDICATOR (CSI) ELECTRIC MOTOR ELECTRONICS COOLANT PUMP EXTERIOR SOUNDER GRN WIRE GRY WIRE HIGH VOLTAGE BATTERY CHILLER (CHSOV) HIGH VOLTAGE BATTERY COOLANT PUMP IGNITION COIL ON PLUG 1 IGNITION COIL ON PLUG 2 IGNITION COIL ON PLUG 3 IGNITION COIL ON PLUG 4 IGNITION COIL ON PLUG 5 IGNITION COIL ON PLUG 6 LEFT FRONT FOG LAMP LEFT HEADLAMP ASSEMBLY LINCOLN EMBLEM LAMP LOWER ACTIVE GRILLE SHUTTER ACTUATOR NCA WIRE POWER STEERING CONTROL MODULE (PSCM) RIGHT FRONT FOG LAMP TRANSMISSION UPPER ACTIVE GRILLE SHUTTER ACTUATOR VIO WIRE WINDSHIELD WIPER MOTOR YEL WIRE

3.0L TURBO 3.0L TURBO HYBRID AIR QUALITY SENSOR AIR SUSPENSION CONTROL MODULE (SUMA) AUXILIARY BATTERY ISOLATOR BLK WIRE BLOWER MOTOR CONTROL MODULE BLU WIRE CABIN HEATER COOLANT PUMP CENTER CONSOLE USB CHARGE PORT CHARGE PORT COOLING FAN MOTOR COOLING FAN RELAY CRUISE CONTROL MODULE (CCM) GRN WIRE GRY WIRE HEADLAMP CONTROL MODULE (HCM) HIGH VOLTAGE BATTERY COOLANT DIVERTER VALVE HIGH VOLTAGE BATTERY COOLANT PUMP HOOD AJAR SWITCH HORN LEFT WINDSHIELD HEATED WIPER NCA WIRE PARKING ASSIST CONTROL MODULE (PAM) PASSENGER DOOR MODULE (PDM) POWERTRAIN CONTROL MODULE (PCM) RIGHT END OF DASH) RIGHT FRONT DOOR LATCH CONTROL MODULE (DCMF) RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT DOOR TWEETER SPEAKER RIGHT FRONT DOOR WINDOW CONTROL SWITCH RIGHT FRONT EXTERIOR DOOR LATCH SWITCH RIGHT FRONT FOOTWELL LAMP RIGHT FRONT INTERIOR DOOR LATCH SWITCH RIGHT FRONT SEAT CONTROL SWITCH RIGHT HEADLAMP ASSEMBLY RIGHT INSTRUMENT PANEL AMBIENT LAMP RIGHT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LAMP RIGHT KEYLESS ENTRY KEYPAD RIGHT KEYLESS ENTRY KEYPAD/ BLUETOOTH ANTENNA 2 RIGHT SCUFF PLATE LAMP RIGHT WINDSHIELD HEATED WIPER SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE A (SOBDM) SECONDARY ON-BOARD DIAGNOSTIC CONTROL MODULE C (SOBDMC) VIO WIRE W/ AIR SUSPENSION W/O PHONE AS A KEY WHT WIRE WINDSHIELD WASHER FLUID LEVEL SENSOR YEL WIRE

ALL TERRAIN CONTROL MODULE (ATCM) BLK WIRE BLU WIRE BLUETOOTH ANTENNA 6 BLUETOOTH ANTENNA 8 CENTER CONSOLE CUP HOLDER AMBIENT LAMP CENTER CONSOLE MEDIA BIN LAMP CENTER CONSOLE PASS THRU AMBIENT LAMP CENTER CONSOLE REAR STORAGE BIN LAMP FAMILY ENTERTAINMENT SYSTEM FRONT CENTER CONSOLE POWER POINT 2 FRONT CONTROLS INTERFACE MODULE-B (FCIMB) GATEWAY MODULE A (GWM) GEAR SHIFT MODULE (GSM) GLOVE COMPARTMENT LAMP GRN WIRE GRY WIRE HEATED SECOND ROW SEAT MODULE INSTRUMENT PANEL SWITCH PACK LEFT FRONT SEAT BELT BUCKLE LEFT SEAT POSITION SENSOR LEFT SECOND ROW SEAT BACKREST HEATER MAT NCA WIRE PARKING BRAKE SWITCH PASSENGER FRONT SEAT MODULE (SCMB) PASSENGER MULTI-CONTOUR SEAT MODULE (SCMH) REAR AUDIO CONTROL MODULE (RACM) REAR HEATING, VENTILATION, AIR CONDITIONING (RHVAC) CONTROL MODULE REAR SEAT CLIMATE CONTROL MODULE (SCMF) REMOTE DATA LINK CONNECTOR (DLC) RIGHT FRONT SEAT (REAR FOOTWELL) LAMP RIGHT FRONT SEAT BACKREST HEATER MAT RIGHT INTERIOR REAR DOOR LOCK INDICATOR/ AMBIENT LAMP RIGHT MULTI-CONTOUR CONTROL PUMP RIGHT REAR DOOR LATCH CONTROL MODULE (DCMH) RIGHT REAR DOOR LOCK SWITCH RIGHT REAR DOOR TWEETER SPEAKER RIGHT REAR DOOR WINDOW CONTROL SWITCH RIGHT REAR EXTERIOR DOOR LATCH SWITCH RIGHT REAR INTERIOR DOOR LATCH SWITCH RIGHT SECOND ROW POWER FOLD SEAT MOTOR RIGHT SECOND ROW SEAT BACKREST HEATER MAT RIGHT SECOND ROW SEAT BELT BUCKLE RIGHT SECOND ROW SINGLE SEAT EASY ENTRY SEAT FOLD SWITCH SECOND ROW BLOWER MOTOR CONTROL MODULE VIO WIRE W/ AMBIENT LIGHTING W/ REAR HEATED SEATS W/O AMBIENT LIGHTING WHT WIRE WIRELESS ACCESSORY CHARGING MODULE (WACM) YEL WIRE

AUTO DIMMING INTERIOR MIRROR BLK WIRE BLU WIRE CLOCKSPRING DIRECT CURRENT/ ALTERNATING CURRENT (DC/AC) INVERTER DOWNSHIFT PADDLE SWITCH DRIVER DOOR MODULE (DDM) GATEWAY MODULE A (GWM) GRN WIRE GRY WIRE HEADLAMP SWITCH HEADUP DISPLAY (HUD) MODULE HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE HORN SWITCH IGNITION SWITCH IMAGE PROCESSING MODULE A (IPMA) INSTRUMENT PANEL CLUSTER (IPC) INTRUSION SENSOR LEFT FRONT DOOR LATCH CONTROL MODULE (DCME) LEFT FRONT DOOR LOCK SWITCH LEFT FRONT DOOR TWEETER SPEAKER LEFT FRONT DOOR WINDOW CONTROL SWITCH LEFT FRONT EXTERIOR DOOR LATCH SWITCH LEFT FRONT FOOTWELL LAMP LEFT FRONT INTERIOR DOOR LATCH SWITCH LEFT FRONT SEAT CONTROL SWITCH LEFT INSTRUMENT PANEL AMBIENT LAMP LEFT INTERIOR FRONT DOOR LOCK INDICATOR/ AMBIENT LAMP LEFT KEYLESS ENTRY KEYPAD LEFT KEYLESS ENTRY KEYPAD/ BLUETOOTH ANTENNA 11 LEFT SCUFF PLATE LAMP LEFT SECOND ROW INTERIOR LAMP LEFT VANITY MIRROR LAMP NCA WIRE OVERHEAD CONSOLE PARTICULATE SENSOR RADIO TRANSCEIVER MODULE (RTM) RAIN SENSOR REMOTE DATA LINK CONNECTOR (DLC) REMOTE FUNCTION ACTUATOR (RFA) MODULE RIGHT SECOND ROW INTERIOR LAMP RIGHT VANITY MIRROR LAMP STEERING COLUMN CONTROL MODULE (SCCM) SYNC MODULE (APIM) THIRD ROW INTERIOR LAMP TRAILER BRAKE CONTROL MODULE (TBM) UPSHIFT PADDLE SWITCH VIO WIRE W/ AMBIENT LIGHTING W/O PHONE AS A KEY WHT WIRE YEL WIRE

AUXILIARY BATTERY BATTERY ENERGY CONTROL MODULE (BECM) BLK WIRE BLUETOOTH ANTENNA 5 BODY CONTROL MODULE (BCM) BRAKE PEDAL POSITION (BPP) SWITCH DRIVER FRONT SEAT MODULE (DSM) DRIVER MULTI-CONTOUR SEAT MODULE (SCMG) FUEL PUMP CONTROL MODULE FUEL PUMP, SENDER UNIT SHIELD GRN WIRE GRY WIRE LEFT FRONT SEAT (REAR FOOTWELL) LAMP LEFT FRONT SEAT BACKREST HEATER MAT LEFT INTERIOR REAR DOOR LOCK INDICATOR/ AMBIENT LAMP LEFT MULTI-CONTOUR CONTROL PUMP LEFT REAR DOOR LATCH CONTROL MODULE (DCMG) LEFT REAR DOOR LOCK SWITCH LEFT REAR DOOR TWEETER SPEAKER LEFT REAR DOOR WINDOW CONTROL SWITCH LEFT REAR EXTERIOR DOOR LATCH SWITCH LEFT REAR INTERIOR DOOR LATCH SWITCH LEFT SECOND ROW POWER FOLD SEAT MOTOR LEFT SECOND ROW SEATBELT BUCKLE LEFT SECOND ROW SINGLE SEAT EASY ENTRY SEAT FOLD SWITCH NCA WIRE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) POWER FOLD SEAT MODULE (SCMJ) RIGHT FRONT SEATBELT BUCKLE RIGHT SEAT POSITION SENSOR SECOND ROW CONSOLE CUP HOLDER AMBIENT LAMP SECOND ROW CONSOLE STORAGE BIN LAMP SECOND ROW SEATBELT BUCKLE CENTER SECOND ROW USB CHARGE PORT SUNSHADE SWITCH TRAILER MODULE (TRM) VIO WIRE W/ FRONT HEATED SEAT WHT WIRE YEL WIRE

14/28 SPEAKER SYSTEM 3.0L TURBO HYBRID AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) AUDIO FRONT CONTROL MODULE (ACM) BLK WIRE BLK/VIO WIRE BLU WIRE BLUETOOTH ANTENNA 10 BLUETOOTH ANTENNA 3 BLUETOOTH ANTENNA 4 BLUETOOTH ANTENNA 7 BLUETOOTH ANTENNA 9 CARGO LAMP CARGO POWER POINT GRN WIRE GRY WIRE HANDSFREE LIFTGATE ACTUATION MODULE HIGH MOUNTED STOPLAMP JOINT CONNECTOR 18 LEFT LICENSE PLATE LAMP LEFT REAR LAMP ASSEMBLY LEFT REAR SIDE MARKER LAMP LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) LEFT THIRD ROW SEAT BELT BUCKLE LIFTGATE LAMP LIFTGATE LATCH LIFTGATE RELEASE SWITCH NCA WIRE PARK/ REVERSE LAMP PEDESTRIAN ALERT CONTROL MODULE (PACM) POWER FOLD SEAT CONTROL SWITCH REAR BLOWER MOTOR SPEED CONTROL REAR EVAPORATOR SHUT OFF VALVE (RHSOV) REAR FOG LAMP REAR GATE TRUNK MODULE (RGTM) REAR HEATER SHUT OFF VALVE (RHSOV) REAR INTERIOR LIFTGATE CONTROL SWITCH REAR LAMP FADE CONTROL MODULE REAR WINDOW DEFROST GRID REAR WINDOW WIPER MOTOR RIGHT LICENSE PLATE LAMP RIGHT REAR LAMP ASSEMBLY RIGHT REAR SIDE MARKER LAMP RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) RIGHT THIRD ROW SEAT BELT BUCKLE ROOF OPENING PANEL MOTOR ASSEMBLIES SHIELD SUBWOOFER AMPLIFIER TELEMATICS CONTROL UNIT (TCU) MODULE TRAILER TOW CONNECTOR VEHICLE DYNAMICS CONTROL MODULE (VDM) VIO WIRE W/ BLIND SPOT MONITORING WHT WIRE
