Lincoln Aviator II (2019-2024) deck tail Wiring diagram
This page shows the only wiring diagram for the component.deck tail, which is found in the car Lincoln Aviator II (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram deck tail (1 of 1)
BIN SENSE
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED (OR BLU/ORG) WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
DECK TAIL
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
LEFT LICENSE PLATE LAMP
LEFT REAR LAMP ASSEMBLY
LEFT TAIL
LIN 14
NCA WIRE
NTC SENSE
ORG/ WIRE
PARK
PARK/REVERSE LAMP
PWM
REAR LAMP FADE CONTROL MODULE
RED WIRE
REVERSE
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP ASSEMBLY
RIGHT LICENSE PLATE LAMP
RIGHT REAR LAMP ASSEMBLY
RIGHT TAIL/
STOP
TAIL
TURN
TURN OUTAGE
VIO WIRE
VIO/WHT WIRE
VPWR
W/ MATRIX SPEED DEPENDENT HEADLAMPS
W/O MATRIX SPEED DEPENDENT HEADLAMPS
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
