Lincoln Aviator I (2002-2005) vaps fbk Wiring diagram
This page shows the only wiring diagram for the component.vaps fbk, which is found in the car Lincoln Aviator I (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vaps fbk (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 VBATT IGN RUN/START
BLK WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
FUSE
GRY/BLK WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LT GRN WIRE
ORG/LT BLU WIRE
PNK/LT BLU WIRE
POWERTRAIN CONTROL MODULE (AT RIGHT SIDE OF ENGINE FIREWALL)
SCP - SCP +
TAN/ORG WIRE
VAPS
VAPS FBK
VARIABLE ASSIST POWER STEERING MODULE (BEHIND RIGHT SIDE OF DASH)
VARIABLE ASSIST POWER STEERING SOLENOID (ON LEFT FRONT OF ENGINE COMPT)
VBATT
VEHICLE SPEED
VSS
WHT/YEL WIRE
Go to component -> Electronic power steering circuit -> VAPS FBK
