Lincoln Aviator I (2002-2005) near left "b" pillar) Wiring diagrams

AUXILIARY JUNCTION BOX (AJB) (RIGHT SIDE OF ENGINE COMPT, AT FENDER APRON) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BATTERY SAVER RELAY BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/WHT WIRE CARGO LAMP ASSEMBLY CARGO SPACE LAMP DOME ON OFF LOCKED OFF 1 2 3 DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) MODULE FRONT INTERIOR MAP LAMPS ASSEMBLY (ON FRONT OF ROOF) FUSE FUSE 25 GLOVE BOX LAMP) GRY WIRE HOMELINK MODULE HOMELINK MODULE (EARLY PRODUCTION) (ON FRONT OF ROOF) HOT AT ALL TIMES HOT AT ALL TIMES CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE HOT IN RUN OR START INBOARD INSTRUMENT CLUSTER JOINT CONNECTOR 1 (IN BATTERY JUNCTION BOX) JOINT CONNECTOR 4 (IN REAR AUXILIARY JUNCTION BOX) LATE PRODUCTION LEFT EXTERIOR REAR VIEW MIRROR LEFT FRONT FOOTWELL LAMP LEFT VANITY MIRROR LAMP LT BLU WIRE LT GRN WIRE LT GRN/ORG WIRE MAIN LIGHT SWITCH MICROPROCESSOR NEAR LEFT "B" PILLAR) ON WITH DOOR OPEN 5 6 MANUAL ON OFF ORG/ WIRE PNK WIRE PUDDLE LAMP RELAY REAR INTERIOR/ MAP LAMPS ASSEMBLY RED/WHT WIRE RIGHT EXTERIOR REAR VIEW MIRROR RIGHT FRONT FOOTWELL LAMP RIGHT VANITY MIRROR LAMP VIO WIRE YEL WIRE

1/2 3/4 5/6 7/8 9/0 BLK WIRE BRN WIRE DRIVER SIDE DOOR LOCK SWITCH GRY/RED WIRE KEY PAD SWITCH ASSEMBLY LEFT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR LICENSE PLATE ASSEMBLY LIFTGATE DOOR LOCK SWITCH LOCK LT BLU WIRE LT BLU/YEL WIRE LT GRN WIRE NEAR LEFT "B" PILLAR) ORG/ WIRE PASSENGER SIDE DOOR LOCK SWITCH PNK PNK WIRE PNK WIRE PNK/ (BETWEEN RIGHT SIDE ``A", ``B" PILLARS) WIRE PNK/BLK WIRE PNK/LT GRN WIRE PNK/ORG WIRE PNK/YEL WIRE RED WIRE RED/ORG WIRE RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR TAN WIRE UNLK UNLK LOCK YEL WIRE
