Lincoln Aviator I (2002-2005) liftgate ajar switch liftgate lock actuator Wiring diagram
This page shows the only wiring diagram for the component.liftgate ajar switch liftgate lock actuator, which is found in the car Lincoln Aviator I (2002-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate ajar switch liftgate lock actuator (1 of 1)
AUXILIARY A/C RELAY
AUXILIARY JUNCTION BOX (AJB) (RIGHT SIDE OF ENGINE COMPARTMENT, AT FENDER APRON)
AUXILIARY TEMPERATURE ACTUATOR
BLK WIRE
CARGO SPACE LAMP
CLASS II
CLASS III
FRONT AUXILIARY A/C SWITCH
HIGH MOUNTED STOP LAMP
ILLUMINATION DIMMER
JOINT CONNECTOR 4 (IN REAR AUXILIARY JUNCTION BOX)
LEFT LIFTGATE TAIL LAMP
LEFT REAR DOOR AJAR SWITCH
LEFT REAR PARK/STOP TURN LAMP
LEFT REAR WINDOW ADJUST SWITCH (ILLUMINATION)
LEFT REVERSING LAMP
LICENSE PLATE ASSEMBLY
LIFTGATE AJAR SWITCH LIFTGATE LOCK ACTUATOR
LIFTGATE DISARM SWITCH
LIFTGATE DOOR LOCK SWITCH
LIFTGATE GLASS ACTUATOR
LOW TIRE PRESSURE MODULE RIGHT REAR DOOR AJAR SWITCH
LT BLU WIRE
NAVIGATION AMPLIFIER
NAVIGATION ELECTRONIC CONTROL UNIT (ECU) MODULE
PARKING AID MODULE (PAM)
PASSENGER SIDE DOOR LOCK SWITCH
REAR INTERIOR MAP LAMPS ASSEMBLY CARGO LAMP ASSEMBLY
REAR WIPER MOTOR ASSEMBLY
RIGHT EXTERIOR REAR VIEW MIRROR
RIGHT FRONT DOOR AJAR SWITCH
RIGHT LIFTGATE TAIL LAMP
RIGHT REAR PARK/STOP TURN LAMP
RIGHT REAR POWER POINT
RIGHT REAR WINDOW ADJUST SWITCH (ILLUMINATION)
RIGHT REAR WINDOW DEFROST GRID
RIGHT REVERSING LAMP RIGHT REAR PARK/STOP/ TURN LAMP
TRAILER TOW BATTERY CHARGE RELAY
TRAILER TOW CONNECTOR
TRAILER TOW PARKING LAMP RELAY CENTRAL SECURITY MODULE (CSM)
TRAILER TOW REVERSING LAMP RELAY PUDDLE LAMP RELAY
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> LIFTGATE AJAR SWITCH LIFTGATE LOCK ACTUATOR
