Lincoln Aviator I (2002-2005) 608 1003 1003 1390 air bag ind ctrl vbatt vbatt tone driver Wiring diagram

1257 1258 1259 1260 SIGNAL + SIGNAL - SIGNAL + SIGNAL - 1 1 1 1261 1262 1263 1264 SIGNAL + REF/GND SIGNAL + REF/GND 608 1003 1003 1390 AIR BAG IND CTRL VBATT VBATT TONE DRIVER 617 618 SIGNAL + REF/GND BATTERY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT, AT FENDER APRON) BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DATA BUS VBATT AIR BAG STAGE 2+ AIR BAG STAGE 2- DATA LINK CONNECTOR (DLC) (PARTIAL) (BEHIND LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DK GRN/ORG WIRE DRIVER 1 SIDE IMPACT SENSOR (UNDER DRIVER'S SEAT) DRIVER SAFETY BELT RETRACTOR PRETENSIONER (UNDER DRIVER'S SEAT) DRIVER'S SAFETY BELT BUCKLE SWITCH (UNDER DRIVER'S SEAT) DUAL AUTOMATIC TEMPERATURE CONTROL (EATC) MODULE (UNDER LEFT DASH PANEL) FUSE GRN WIRE GRY WIRE GRY/ORG WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER J/C 1 LOGIC GROUND LT BLU WIRE LT BLU/ORG WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT LT MICRO- PROCESSOR NOTE: 1: UNBUCKLED 2: BUCKLED ORG/ WIRE PASSENGER 1 SIDE IMPACT SENSOR (UNDER FRONT PASSENGER'S SEAT) PASSENGER SAFETY BELT RETRACTOR PRETENSIONER (UNDER PASSENGER'S SEAT) PASSENGER'S SAFETY BELT BUCKLE SWITCH (UNDER PASSENGER'S SEAT) PNK/BLK WIRE PNK/ORG WIRE RED WIRE RED/ORG WIRE RED/WHT WIRE RESTRAINT CONTROL MODULE (RCM) (BELOW CENTER CONSOLE) SHORTING BAR TAN/BLK WIRE TWISTED PAIRS WIRES VIO/LT GRN WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE
