Car Wiring Diagrams for Immobilizer circuit for Lexus UX I (2018-2024)

BLK WIRE BLU WIRE CERTIFICATION ECU (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM ECU-B 1 FUSE EFII EFIO EXCEPT HYBRID GRY WIRE HOT AT ALL TIMES HYBRID VEHICLE CONTROL ECU ID CODE BOX (IMMOBILIZER CODE ECU) IMI IMO INSTRUMENT PANEL J/B ASSEMBLY LIN LT BLU WIRE STEERING COLUMN) STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY VIO WIRE WHT WIRE
