Lexus UX I (2018-2024) interlock switch Wiring diagrams
This page contains all the electrical diagrams for the component. interlock switch, in which he is found in the car Lexus UX I (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram interlock switch (1 of 2)
2.0L
2.0L HYBRID
BATTERY COOLING BLOWER ASSEMBLY
BLK WIRE
DOOR CONTROL SWITCH ASSEMBLY
FUEL PUMP CONTROL ECU
HV BATTERY JUNCTION BLOCK ASSEMBLY
IGCT RELAY
INTERLOCK SWITCH
LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY
LEFT FRONT POWER SEAT SWITCH ASSEMBLY
LEFT FRONT SEAT BACK HEATER ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
LEFT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR DOOR LOCK W/ MOTOR ASSEMBLY
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
LEFT SEAT MEMORY SWITCH
NA (LEFT "B" PILLAR)
NE (RIGHT "C" PILLAR)
OCCUPANT DETECTION ECU
OUTER MIRROR SWITCH ASSEMBLY
POWER WINDOW REGULATOR SWITCH ASSEMBLY
PPL
R/B 3 ASSEMBLY
REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT POWER SEAT SWITCH ASSEMBLY
RIGHT FRONT SEAT BACK HEATER ASSEMBLY
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR COMBINATION LIGHT LED
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT SEAT CUSHION CONTROL BLOWER ASSEMBLY
THEFT WARNING SIREN ASSEMBLY
TO GROUND NB (DIAGRAM 5 OF 6)
VEHICLE APPROACHING SPEAKER CONTROLLER
W/ CLIMATE CONTROL SEAT
W/ MEMORY
W/ SEAT HEATER
W/O MEMORY
W/O SEAT HEATER
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 6) -> INTERLOCK SWITCH
Wiring diagram interlock switch (2 of 2)
+BWP
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CRANK POSITION SENSOR (LOWER LEFT REAR OF ENGINE)
ECU-ACC FUSE
ENGINE ROOM R/B 1
EV MODE
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
ILK
INSTRUMENT PANEL J/B ASSEMBLY
INTERLOCK SWITCH
INVERTER WATER PUMP W/ MOTOR ASSEMBLY
LT GRN WIRE
NE+
NEO
NORM
NORMAL SWITCH
NWP
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SATELLITE SWITCH SET
SPORT SWITCH
SPSW
SWP
VCNE PNK NE- WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.0l hybrid, hybrid system circuit (5 of 8) -> INTERLOCK SWITCH
