Lexus UX I (2018-2024) front wiper switch Wiring diagram
This page shows the only wiring diagram for the component.front wiper switch, which is found in the car Lexus UX I (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front wiper switch (1 of 1)
-WR
AUTO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECU-B 4 FUSE
ENGINE ROOM R/B 1
EWS
FRONT WIPER SWITCH
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IGWS
INSTRUMENT PANEL J/B ASSEMBLY
INTERMITTENT
LIN
LT GRN WIRE
MIST
MOTOR
OFF
ORG/ WIRE
PPL
PPL/LT GRN WIRE
PPL/PNK WIRE
R/B 2
R/B 3 ASSEMBLY
REAR WIPER/ WASHER CIRCUIT
RED WIRE
STEERING COLUMN)
STEERING SENSOR
STEERING WHEEL SWITCH HOUSING
VOLUME SWITCH
W-OFF
W/O AUTO WIPER SYSTEM
WASHER FUSE
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER RELAY ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
WIPER RELAY
Go to component: -> Front wiper/washer circuit (1 of 2) -> FRONT WIPER SWITCH
